Used Complete Herbold Wash Line
Additional information
| Bale Breaker | – |
|---|---|
| Bale Breaker Brand | Mooge |
| Bale Breaker Voltage | 480V/3Ph/60Hz |
| Trommel | – |
| Trommel Motor Voltage | 480V/3Ph/60Hz |
| Trommel Motor RPM | 1752 |
| Granulator | – |
| Granulator Brand | Herbold |
| Granulator Type | SML 60/100-S5-2 |
| Cutting Chamber Opening | 720mm x 980mm (Approx.) |
| Rotor Diameter | 600mm |
| Rotor Length | 980mm |
| Rotor Knives | 5×2 |
| Stator Knives | 2×1 |
| Granulator Drive Motor | 108 kW, 460V/3Ph/60Hz |
| Sink Float Tank | – |
| Tank Dimensions | 3000mm L x 1100mm W (Approx.) |
| Overall Length | 6765mm (Approx.) Including Discharge Scraper |
| Drive Paddle Rollers | 3 Drive Paddle Rollers – 0.37 kW Each |
| Discharge Drum | 1 Discharge Drum – 0.55 kW (Approx.) |
| Discharge Scraper | 1.1 kW (Approx.) |
| Frictional Washer | – |
| Frictional Washer Series | FA3000 |
| Conveying Length | 3000mm (Approx.) |
| Screw Diameter | 500mm (Approx.) |
| Screen Size | 2.5mm |
| Washer Drive | 18.5 kW |
| Rotor Speed | 1000 RPM |
Request A Quote
PlastiWin Capital Equipment, LLC. has just located this Used Complete Herbold Wash Line for sale. It comes complete and ready for a new home. It is priced to sell so call us today at (330) 998-6738 to set up your inspection or for any other Size Reduction & Recycling needs!
